Tanks & Secondary Containment
Tanks & Secondary Containment
Planned and reactive maintenance is supported by our range of chemical protection products from Highlands Performance Resins and our manufacturing partners. We can also help you specify the most suitable products for your requirements.
HPR Epoxy Coating 152-LV
Properties
HPR Epoxy Coating 152-LV is a high build solvent-free epoxy coating designed for the long-term protection of steel and concrete structures against corrosion, abrasion and chemical attack. Operating temperature ranges from –20°C to 60°C (140°F). The two-component product is highly…
Applications
>Pipelines >Tank Internals >Chemical Containment >Bund Areas >Sheet & Bearing Piles >Sumps >Chemical Intake Areas >Chemical Pits >Structural Steel
Colours & Unit Size
Colours: >Light Grey >Dark Grey >Mid Blue Unit Size: >3.4L >16L
Coverage & Cure Time
Coverage: >Approx. 4M² per L at 250µ Cure Time: >Light Loading: Approx. 6-8 Hours at 20°C >Chemical Contact: Approx. 5 Days at 20°C
Pot Life & VOC
Pot Life: >Approx. 20-25 Minutes at 20°C VOC: >0g/L
HPR Epoxy Coating 175-UC
Properties
HPR Epoxy Coating 175-UC is a high build solvent-free epoxy novalac coating designed to provide outstanding chemical and corrosion protection of steel and concrete structures. The coating is particularly resistant to attack by strong acids including 98% sulphuric acid. Please read…
Applications
>Chemical containment areas >Tank linings >Pumps >Chemical drains and channels >Pipework
Colours & Unit Size
Colours: >Dark Grey >Red Unit Size: >4L >16L
Coverage & Cure Time
Coverage: >Approx. 4M² per L at 250µ Cure Time: >Touch Dry: Approx. 6 Hours at 20°C >Full Cure: Approx. 7 Days at 20°C
Pot Life & VOC
Pot Life: >Approx. 20-25 Minutes at 20°C VOC: >0g/L
HPR Epoxy Coating 175-UCF
Properties
HPR Epoxy Coating 175-UCF is a high build solvent-free high functionality epoxy novolac coating designed to provide outstanding chemical and corrosion protection of steel and concrete structures at elevated temperatures. Designed for application on chimneys, chemical containment and bund areas, tanks,…
Applications
>Chimneys >Chemical Containment >Bund Areas >Tanks >Pumps & Valves >Chemical Drains >Pipework
Colours & Unit Size
Colours: >Dark Grey >Red Unit Size: >1L >4L >16L
Coverage & Cure Time
Coverage: >Approx. 2.9M² per L at 350µ Cure Time: >Touch Dry: Approx. 6 Hours at 20°C >Full Cure: Approx. 7 Days at 20°C
Pot Life & VOC
Pot Life: >Approx. 15-20 Minutes at 20°C VOC: >0g/L
HPR Epoxy Primer 810-SP
Properties
HPR Epoxy Primer 810-SP is an epoxy resin based solvent free thin film primer specifically developed to be used on concrete and cementitious surfaces. On curing the product consolidates the substrate and helps to improve adhesion during application of other…
Applications
>Concrete Floors >Problematic Cementitious Surfaces
Colours & Unit Size
Colours: >Amber Unit Size: >4L >18L
Coverage & Cure Time
Coverage: >Approx. 6.6M² at 150µ Cure Time: >Touch Dry: Approx. 8 Hours at 20°C >Full Cure: Approx. 3 Days at 20°C
Pot Life & VOC
Pot Life: >Approx. 45 Minutes at 20°C VOC: >0g/L
HPR Urethane Coating 165-PU
Properties
HPR Urethane Coating 165-PU is a high build solvent free urethane anticorrosive coating designed for the efficient long-term protection of pipelines, pipe fittings and equipment. HPR-165-PU also meets the requirements of BS6920:1990 as required by the Water Research Centre. It's designed…
Applications
>Pipelines >Water Tanks >Effluent Systems >Pumps & Valves >Marine Structures >Potable Water Environments
Colours & Unit Size
Colours: >Mid Grey >Cream >Mid Blue Unit Size: >1L >4L >80L (4 x 20L)
Coverage & Cure Time
Coverage: >2M² per L at 500µ Cure Time: >Touch Dry: Approx. 2 Hours at 20°C >Full Cure: Approx. 7 Days at 20°C
Pot Life & VOC
Pot Life: >Approx. 15-20 Minutes at 20°C VOC: >0g/L
Approvals
>BS6920:1990
Acothane DW
Properties
From £27.75 per litre A Price Pledge product=#100926# DWI approved - (always read the instruction for use) The Drinking Water Inspectorate (DWI) was formed to provide independent reassurance that water supplies in England and Wales are safe and drinking water quality is acceptable…
Applications
Internal & external coating and lining for metallic, cementitious, composite and GRP... >Tanks >Vessels >Resevoirs >Pipelines >Pipe Bends >Valves >Fittings
Colours & Unit Size
Colours: >Blue >Cream >Grey >Clear (LV Sealer) Unit Size: >2L >4L >3.5L (LV Sealer)
Coverage & Cure Time
Coverage: >Approx. 1M² per litre at 1000µ >Approx. 6M² per litre dependent on surface porosity (LV Sealer) Cure Time (at 20°C): >Touch Dry: Approx. 30 minutes (spray) >Touch Dry: Approx. 2 hours (brush) >Hard Dry: Approx. 5-6 hours >Full Cure: Approx. 7 days >Touch Dry: Approx.…
Pot Life & VOC
Pot Life: >Approx. 30 minutes at 20°C VOC: >0 g/L
Approvals
>DWI Approval
CIM 1000
Properties
Contract specification & pricing available A liquid applied urethane coating that cures in hours to form a tough elastomeric coating that adheres to most substrates, forming a chemical and abrasion resistant barrier for waterproofing, corrosion protection, and containment of water and…
Applications
>Concrete >Crack Bridging
Colours & Unit Size
Colours: >Shiny Black (turns dull over 3-6 months in sunlight) Unit Size: >5 Gallons
Approvals
>ANSI 118.10-199
CIM 1000 Trowel Grade
Properties
Contract specification & pricing available A tough, liquid applied, two-component, chemical and corrosion resistant urethane elastomeric coating, chemically thickened to allow trowel applications with minimum sag. It’s designed for use with all CIM materials and can be used as a crack…
Applications
>Concrete >Crack Bridging
Colours & Unit Size
Colours: >Shiny Black (goes dull after 3-6 months in sunlight) Unit Size: >0.8 Gallon >4.5 Gallon
